The Versatran 20T Retriever is a heavy-duty equipment transport truck built on a 2027 Western Star 47X tri-axle chassis. Its 28-foot, low-profile transport deck, air-operated loading system, and integrated tie-down points support the loading, securing, and hauling of drilling, construction, and industrial equipment. The no-idle system allows deck and ramp operation with the truck engine shut off, helping streamline equipment movement at the jobsite.
Key Features
• No-Idle System: Allows loading and unloading with the truck engine turned off, helping reduce wear and tear during equipment loading.
• Low-Angle Bed Design: The curved deck creates a low loading angle to help simplify loading and unloading equipment.
• Flexible Transport Solution: One Retriever can support the work of several different types of transport trucks.
• Air-Operated Deck and Ramp: Designed for efficient operation while reducing concerns related to hydraulic fluid spills and cold-weather hydraulic warm-up delays.
• Heavy-Duty Deck Design: High-strength steel deck with multiple tie-down points for securing equipment.
• Transport-Ready Setup: Equipped with lighting, winch, chain storage, camera, and control features to support field transport needs.
Unit Specifications
• Chassis Make: Western Star
• Chassis Model: 47X
• Chassis Model Year: 2027
• Chassis Type: Tri-axle truck
• Engine: Cummins X12, 500 HP
• Transmission: Allison 4000 RDS automatic transmission with PTO provision
• GVWR: 64,860 lbs.
• Rated Capacity: 20 tons / 40,000 lbs (not legal payload)
• Bed Size: 28 ft L x 102 in W
• Ramp: Single-stage ramp
• Trailer Hitch: Class 7 receiver, up to 14,000 lbs ball hitch / 18,000 lbs with Class 7 pintle hitch
Standard Features
• Air-operated deck and 3-position ramp
• Exclusive no-idle operating system
• Patented low-angle bed design
• High-strength steel deck
• High-strength steel headboard
• 140 key slot tie-down points
• Lockable, lighted aluminum control box
• All LED lighting
• Weatherproof harnesses throughout
• Slip-resistant epoxy deck coating
• Primed and powder-coated finish
• 15,000 lb Warn electric winch, traverse mounted
• Aluminum chain rack with tray
• Under-deck chain storage boxes
• Chain binder storage racks
• LED dual mini light bars, 11″
• Four extra-high intensity side beacons
• Upper LED work lights
• Lower LED work lights
• Backup camera system, single camera
• Trailer plug, 7-pole house trailer type
• Trailer plug, 7-pole round
• Electric brake controller
• Air trailer brake connections
• Winch and chain tray guard
Specifications are provided for general reference and may vary by unit configuration.
Interested in this Versatran Western Star 20T Retriever? Contact Rig Source at (630) 365-1649 to confirm current availability, rental options, purchase options, pricing, and configuration details.
