Unit Specifications
• Year: 2026
• Engine: Kubota V2403 T4 / Stage V
• Horsepower: 65 hp
• Head Travel: 105 in / 8.75 ft
• Head Push Force: 36,000 lbs
• Head Pull Force: 48,000 lbs
• Rotary Drive: GR6.5
• Spindle adapter size: 1-5/8
• Primary Pump: Axial piston LS/HP limited
• Primary Pump Max Pressure: 4,000 psi
• Primary Pump Max Flow: 40 gpm
• Dimensions, Transport: 80 in W x 214 in L x 114 in H
• Fuel Capacity: 17 gal
Winch Package
• 4500lbs Main winch
• 2100lbs Tool winch
Breakout
• Breakout table
• Breakout wrench
Standard Features
• Geotech Head Assembly GR6.5
• Drill Mast Outrigger Kit 3100GT
• Moyno 3L6 Assembly with table, operator side
• Extruder Kit 3126GT, 60″
• 3126 Water Swivel Assembly
• Drop Rack System with 150-gallon tank
• Direct push hammer assembly GH6400
